Qadiri Distributors
Voice coil size - 2.75 inch
Cone - Paper
Magnet - Ferrite
Voice coil wire - CCAW
Surround - Foam
RMS Power - 1500W RMS
MAX Power - 3000 W
Frame - Alu
Impedance - 1+1 / 2+2 Ohm
SPL - 86.20 / 86.20 dB
Fs - 31.12 / 31.12 Hz
Qts - 0.36 / 0.36
BL - 20.83 / 20.83
Vas - 30.74 / 30.74 L
Xmeh - 36.00 / 36.00 mm
Xmax - 18.00 / 18.00 mm
Mounting depth - 7.07 inch (179.5 mm)
Cut-out dimension - 11.00 inch (279.3 mm)
Gross weight - 30.64 lb (13.90 kg)
