XTC Audio WILDFIRE 12 000W Class D Monoblock Amplifier

XTC Audio WILDFIRE 12 000W Class D Monoblock Amplifier

WILDFIRE

Please view price list or log in to see wholesale pricing.

General Specifications

  • Digital class D linkable monoblock amplifier
  • Wired Remote Control Included
  • IN CAR RMS 1300>@ 1 Ohm
  • Manufacturer rated RMS 2000 unconfirmed
  • MOSFET PWM power supply
  • Double sided through hole epoxy PCB
  • Stable into 1 Ohm and 2 Ohms parallel amplifier connection availability
  • 24db/oct variable crossover
  • Variable subsonic filter
  • Variable bass boost
  • Variable low pass filter
  • Variable phase shift
  • Efficiency: 86%@4 ohms at 100Hz
  • Multi-way protection circuitry (Thermal / over current / speaker short / speaker DC protection)
  • RCA line input
  • Tested voltage & THD: 14.4V & less than 1% THD
  • Operating voltage: DC10v – 15V power input
  • Signal to noise ratio: >95db
  • Low pass frequency crossover: 40Hz – 200Hz
  • Subsonic filter: 0Hz – 50Hz
  • Bass boost @ 45Hz: 0 – 12db
  • Phase shift control: 0 – 180 degree
  • Frequency response: 10Hz – 200Hz (-3db)
  • T.H.D @ 4 Ohms: <1%
  • Efficiency @ 4 Ohms: 86%
  • Fuse rating: 30A x3
  • Input sensitivity: 150Mv-5v (+/-5%)

    •
